Balder™ 40mm ceiling tile sound absorbing
kr 866 kr 606 pr. m² inc.vat
Extremely good sound absorption. Sound attenuation, class A. 40 mm absorber for system ceiling for optimised acoustic solution.
The product has excellent sound absorption and light reflection properties
Sound absorber. An edge.
For larger orders, please request offer.
Description
Ceiling panel developed specifically for installation in a T-system with 200 mm air above. Can also be glued/attached to the wall where there is no space for a traditional suspension system.
Kant: A (straight edge)
The panel has a traditional textured surface with a specially elaborate edge seal. The panel has excellent sound absorption and is highly sound-absorbing. The panel also has a coating on the surface that makes it easier to maintain and gives it a long service life compared to more traditional absorbers on the market. With its high light reflection, it is therefore very suitable for most types of rooms; in detached houses, sound studios, office and teaching environments, kindergartens, multi-purpose rooms, canteens and generally rooms with a lot of noise.
Colour. The closest colour code is NCS S0502-Y. Light reflection is 84%. The panels are available in edge design A. Special colours can be ordered (minimum quantity is 100 m2)
Fire class. A2-s1,d0, according to EN 13501-1
The product is M1 certified. This means that the product has been tested and fulfils the strictest international requirements for emissions and non-use of toxic components. There are special requirements for acoustic products that must be met to obtain M1 certification.
EPD (Environmental Product Declaration). The product has completed the LCA (Life Cycle Assessment) report and received an EPD (Environmental Product Declaration) certificate.
Cleaning and maintenance. The panel has a surface that allows for dusting, vacuuming and gentle washing with a slightly damp cloth. If the disc is painted over, it will lose its properties.
Additional information
Size (mm) | 592 x 592, 592 x 1192 |
---|
Data sheets and documentation
Norwegian
English:
Acoustics
The disc is classified as Class A
The absorption test is carried out in accordance with ISO 354:2003 with 200 mm of air behind the panels.
NRC = 0.95. The absorption coefficient (αw) is calculated to 1.00 according to ISO 11654.
Installation
For assembly, it is necessary to use a HIMLING SYSTEM.
You may also like…
-
Cross profile. Length 600 mm
For t-system, ceiling system.
L:600, H: 38, W:24mm. Thickness: 0.3 mm
-
Cross profile. Length 1200 mm
For t-system, ceiling system.
L:1200, H:38, W:24mm. Thickness: 0.3mm
-
Main profile. Length 3000 mm
For t-system, ceiling system.
L:3000, H:38, W:24 mm. Thickness: 0.3mm
Sold per piece.
(Carton 25 pcs)
